Input Voltage working range

125V to 300V ±110VAC

I/PV range @ Full Rated o/p current

185V-285V ±10VAC

Input frequency

47-63 Hz

Input power factor

≥ 0.96

Max. output voltage

81.25V ±1V

Output current

18A ± 1A

Half Mode Output Current @ I/P Range 90V-170V

9A ± 1A

Efficiency @full load

≥ 90% @ Full Load

Line / Load Regulation

< 2%

Charging profile

4 STAGE (BOOST, ABSORPTION, EQUALIZING & FLOAT)

Operating Temperature

0°C to +50°C

Storage Temperature

-10°C to +60°C

Dimensions

312(L) X 155(W) X 95(H)

Net Weight

3.1Kg

Gross Weight

3.5Kg
