Product Warranty

2 years

Input Voltage working range

125-300V ± 10V

I/P Voltage range @ Full Rated o/p current

170-280V ± 10V

Input frequency

47-63 Hz

Input power factor

0.995 TO 0.925 UPTO 270V, DERATE AFTER 270V

Max. output voltage

57.4V±1VDC

Output current

25 ± 1A

Half Mode Output Current

11 ± 1A

Efficiency @ 220VAC @ Full current & nominal DC Bus

>90%

Line / Load Regulation

< 2%

Charging profile

CC-CV

Operating Temperature

0°C TO +50°C

Storage Temperature

10°C TO +60°C

Dimensions

282*160*92

Dimensions with packing

410*204*156

Net Weight ( Kg)

3.18

Gross Weight (Kg)

3.76
